Skelmir S12

AUV-TORPEDO FAMILY OF SYSTEMS

The Skelmir S12 Modular Underwater Effector is an advanced autonomous system designed to fill the role of AUV & lightweight torpedo, and all the white space in between. This innovative, expendable, and modular underwater system is rapidly manufacturable, offering an effective solution to attrit threats, deploy sensors and decoys on a large scale. Vatn’s mission software enables one user to plan and monitor hundreds of units, a true force multiplier.

AUV Configuration

Technical Specifications

  • INITIALIZABLE IN GPS DENIED ENVIRONMENTS

  • SHOCK RESISTANT

  • GPS SPOOFING/JAMMING RESISTANT

  • SOCOM MOD PAYLOAD COMPLIANT

  • ANDROID TACTICAL ASSAULT KIT PLUGIN

  • VARIOUS PAYLOADS AVAILABLE

FEATURES

  • SPEED: 30+ kts

  • LENGTH: 14-20 ft

  • RANGE: 200+ nm

  • PAYLOAD WEIGHT: 200+ lbs

  • DEPTH: 300+ m

  • WEIGHT: 600-800 lbs

  • DIAMETER: 12.75 in

Torpedo Configuration

Technical Specifications

  • SPEED: 30+ kts

  • LENGTH: 9 ft

  • RANGE: 100+ nm

  • PAYLOAD WEIGHT: Up to 200 lbs

  • DEPTH: 300+

  • WEIGHT: ~600 lbs

  • DIAMETER: 12.75 in

FEATURES

  • HEYRA ACTIVE/PASSIVE SEEKER

  • SHOCK RESISTANT

  • 1:1 REPLACEMENT FOR MK54

  • FLEXIBLE SPEED ENABLING LONG RANGES AT LOWER SPEEDS

  • ANDROID TACTICAL ASSAULT KIT PLUGIN

  • LAUNCH FROM ANY PLATFORM ANYWHERE

FLEXIBLE DEPLOYMENT

USV

AIR

SUB

UAV

SMALL CRAFT

SHIP

Tactical forces deploy Vatn AUEs en masse to address high volume threats with reduced risk to force and expanded capability for commanders

UNMATCHED OPERATIONAL FLEXIBILITY  IN A2AD ENVIRONMENTS

The Skelmir S12 offers a solution volume manufactured and priced for mass deployment to threaten adversary fleet assest and logistics. Easily deployed by SOF, air assets, and traditional Naval platforms, it infiltrates enemy defenses undetected with over-the-horizon covert capabilities. S12 can deliver a wide variety of payloads including kinetic, electromagnetic, cyber, or sensor capabilities without requiring vessel integration. It excels in A2AD environments no matter the configuration or role.

ENHANCED CONTROL AND INTEGRATION WITH ATAK

Operators control Skelmir and plan missions through Vatn’s ATAK (Android Team Awareness Kit) plugin via tablet or phone, which ensures streamlined integration into existing command and control systems. This user-friendly interface allows for efficient mission planning, real-time updates, and enhanced situational awareness, making Skelmir an even more versatile and effective tool for maritime operations.
